用Canvas实现图片滤镜效果详解之视频效果

这是一个很有意思的特效，模拟摄像机拍摄电视屏幕画面时出现点状颗粒的效果。颗粒的大小通过变换矩阵实现，可以任意调节，有兴趣研究的朋友可以尝试更多的效果，代码没有经过优化，只是一个粗糙的Demo，大家可以自行改进。

获取图像数据

img.src = ’original.jpg’;
canvas.width = img.width;
canvas.height = img.height;
var context = canvas.getContext(“2d”);
context.drawImage(img, 0, 0);
var canvasData = context.getImageData(0, 0, canvas.width, canvas.height);

设置过滤矩阵

var m_VideoType=0;
       var pattern=new Array();
       switch (m_VideoType)
       {
           case0://VIDEOTYPE.VIDEOSTAGGERED:
           {
               pattern = [
                   0, 1,
                   0, 2,
                   1, 2,
                   1, 0,
                   2, 0,
                   2, 1,
               ];
               break;
           }
           case1://VIDEOTYPE.VIDEOTRIPED:
           {
               pattern = [
                   0,
                   1,
                   2,
               ];
               break;
           }
           case2://VIDEOTYPE.VIDEO3X3:
           {
               pattern =
               [
                   0, 1, 2,
                   2, 0, 1,
                   1, 2, 0,
               ];
               break;
           }
           default:
           {
               pattern =
               [
                   0, 1, 2, 0, 0,
                   1, 1, 1, 2, 0,
                   0, 1, 2, 2, 2,
                   0, 0, 1, 2, 0,
                   0, 1, 1, 1, 2,
                   2, 0, 1, 2, 2,
                   0, 0, 0, 1, 2,
                   2, 0, 1, 1, 1,
                   2, 2, 0, 1, 2,
                   2, 0, 0, 0, 1,
                   1, 2, 0, 1, 1,
                   2, 2, 2, 0, 1,
                   1, 2, 0, 0, 0,
                   1, 1, 2, 0, 1,
                   1, 2, 2, 2, 0,
               ];
               break;
           }
       }
       var pattern_width = [ 2, 1, 3, 5 ];
       var pattern_height = [6, 3, 3, 15 ];

获取过滤数据

for ( var x = 0; x < canvasData.width; x++) {
         for ( var y = 0; y < canvasData.height; y++) {

           // Index of the pixel in the array
           var idx = (x + y  canvasData.width)  4;
           var r = canvasData.data[idx + 0];
           var g = canvasData.data[idx + 1];
           var b = canvasData.data[idx + 2];
              var nWidth = patternwidth[mVideoType];
              var nHeight = patternheight[mVideoType];
              var index = nWidth * (y % nHeight) + (x % nWidth);

              index = pattern[index];
              if (index == 0)
               var   r = fclamp0255(2 * r);
              if (index == 1)
               var   g = fclamp0255(2 * g);
              if (index == 2)
               var   b = fclamp0255(2 * b);

            // assign gray scale value
            canvasData.data[idx + 0] = r; // Red channel
            canvasData.data[idx + 1] = g; // Green channel
            canvasData.data[idx + 2] = b; // Blue channel
            canvasData.data[idx + 3] = 255; // Alpha channel
            // 加上黑色的边框
            if(x < 8 || y < 8 || x > (canvasData.width - 8) || y > (canvasData.height - 8))
            {
              canvasData.data[idx + 0] = 0;
              canvasData.data[idx + 1] = 0;
              canvasData.data[idx + 2] = 0;
            }
         }
    }

写入过滤后的数据

context.putImageData(canvasData, 0, 0);

效果预览

原图

效果图

查看示例

参考资料

代震军ImageFilter开源项目
